Overview
Tefabloc TPE is a high performance flexible filament, offering excellent low temperature properties and a high level of hardness stability across a wide temperature range, making it particularly suited for outdoor applications. Tefabloc TPE is resistant to oil, grease, abrasion and solvents and suitable for applications requiring flexibility such as window seals, grips, holders, plugs, robot parts and protective components.
Product Details
Part Number: 55511
- High performance thermoplastic polyester elastomer (TPE) for material extrusion
- Highly flexible
- Resistant to oil, grease, abrasion and solvents
- Good shape retention
- Good weather resistance
- Main applications: Flexible items such as brackets, insoles for shoes, hoses, bracelets, insulation, balls, wheels etc.
Specifications
| Product Specifications | |
|---|---|
| Diameter accuracy: | 1.75 ± 0.05 mm |
| Material net weight: | 0.5 kg |
| Filament length: | 190 m |
| Filament Thickness: | 1.75 mm |
| Melt temperature: | 175 to 195 °C |
| Melt Flow Rate @ 230 °C, 21.1N: | 45 g/(10 minutes) |
| Density: | 1.09 g/cm3 |
| Durometer Hardness: | Shore A85 |
| Tensile yield: | 14 MPa |
| Tensile elongation: | 990 % |
| Spool Dimensions | |
|---|---|
| Spool diameter: | 200 mm |
| Spool depth: | 72 mm |
| Hub diameter: | 102 mm |
| Hub hole diameter: | 51 mm |
| Recommended Printer Set Up | |
| Extrusion temperature: | 230±10 °C |
| Bed temperature: | 60 °C |
| Printing speed: | 20 mm/s |
Models
| Part Number | Filament diameter | Filament weight | Colour | RAL code |
|---|---|---|---|---|
| 55512 | 2.85 mm | 500g | White | 9016 |
| 55513 | 2.85 mm | 500g | Black | 9004 |
| 55510 | 1.75 mm | 500g | White | 9016 |
| 55511 | 1.75 mm | 500g | Black | 9004 |
